Product overview
① The series has compact design, small host width and good passability. Use variable amplitude working arm. Ensures a strong load carrying capacity in a smaller width.
② The width of the main machine is the smallest in all the sliding machine products. To meet special operational requirements.
③ The product uses imported European and American hydraulic parts. Sensitive control, rapid response, is the best choice for small space operations.
Operating load (kg) | 300 |
Maximum driving speed: (high speed) | 8 |
Minimum travel speed: (low speed) | 4 |
Tire(track) model | 18*8.5-8 |
Engine brand: | Briggs&Stratton |
Rated power (HP) | 13.5HP |
Fuel tank capacity (L) | 20 |
Machine net weight: (kg) | 800 |
Working weight: | 1200KG |
Bucket capacity (m3) | 0.15 |
Overall operating height (mm) | 2750 |
Height to bucket hinge pin (mm) | 2200 |
Overall length ithout bucket(mm) | 2180 |
overall length with bucket(mm) | 2680 |
Dumping angle at maximum height(°) | 38 |
Dumping height(mm) | 1770 |
Dumping reach(mm) | 200 |
Wheelbase(mm) | 950 |
Ground clearance(mm) | 140 |
Big arm width: (mm) | 340 |
Width (mm) | 960 |
Bucket width (mm) | 1000 |
This Crawler Skid Steer Loader, also known as a Skid Steer or Skid Steer Loader, features:
Product: | Mini Skid Steer Loader |
Type: | Crawler Skid Steer Loader / Wheel Skid Steer Loader |
Height to bucket hinge pin (mm): | 2200 |
Rated power (HP): | 13.5HP |
Overall length ithout bucket(mm): | 2180 |
Overall operating height (mm): | 2750 |
Engine brand: | Briggs&Stratton |
Maximum driving speed (high speed): | 8 |
Minimum travel speed (low speed): | 4 |
Fuel tank capacity (L): | 20 |
Working weight: | 1200KG |
Operating load (kg): | 300 |
Made in Shandong, China, and certified with CE and EPA, this powerful and reliable skid steer loader is perfect for a variety of applications. With a minimum order quantity of just one set and a negotiable price, it's an affordable investment for any business.
The HTHY800-Y model offers a maximum driving speed of 8, making it easy to move around your job site quickly. And with a low-speed setting of 4, you can easily maneuver in tight spaces. Plus, the 18*8.5-8 tire (track) model provides excellent traction on a variety of surfaces.
The mini skid steer loader's compact size is perfect for small spaces, but don't let its size fool you - it can still lift up to 800kg! The dumping angle at maximum height is 38°, so you can easily dump materials where you need them.
Whether you're moving dirt, gravel, or other materials, the HIGHTOP Mini Skid Steer Loader is up to the task. It's also great for digging, grading, and other landscaping tasks. And with its wooden case packaging and delivery time of just 5-14 work days, you'll have your new skid steer up and running in no time.
Choose from a variety of payment terms, including Western Union, MoneyGram, T/T, D/A, D/P, and L/C. And with a supply ability of 100 sets per month, you can be sure that you'll get the skid steer loader you need when you need it.
Get the job done quickly and efficiently with the HIGHTOP Mini Skid Steer Loader. Order yours today!
Our Wheel Skid Steer Loader has an overall operating height of 2750mm and a fuel tank capacity of 20 liters. The dumping angle at maximum height is 38°, and the overall length without the bucket is 2180mm. The rated power is 13.5HP, and we can supply up to 100 sets per month to meet your demands.
The Mini Skid Steer Loader is a compact and versatile machine used for a variety of applications, including landscaping, construction, and agriculture. Our product technical support and services team is committed to providing the best possible assistance to our customers, ensuring that they can get the most out of their Mini Skid Steer Loader.
We offer a range of technical support and services, including:
Our team is dedicated to providing prompt and reliable technical support and services to ensure that our customers are satisfied with their Mini Skid Steer Loader and get the most value from their investment.
Product Packaging:
The Mini Skid Steer Loader will be packaged in a sturdy cardboard box with foam padding to ensure safe transportation. The box will be labeled with the product name, model number, and handling instructions.
Shipping:
The Mini Skid Steer Loader will be shipped via ground transportation to the customer's specified address. Shipping costs will vary depending on the destination and the weight of the package. The customer will receive a tracking number once the product has been shipped.
