| Place of Origin | China |
| Brand Name | HIGHTOP |
| Certification | CE，EPA，ISO，TUV |
| Model Number | HTS50 |
It is equipped with multiple functional configurations such as a quick - change device, a safety self - locking device, a boom support device, noise - reducing sponge, a front hydraulic auxiliary device, a reversing alarm, and a horn.
Chain box: A tandem piston pump with stepless speed change technology is adopted to drive the hydrostatic motors on the left and right sides.
Optional parts: 10 - 16.5 - 12PR RG400 heavy - duty tires, as well as solid tires with the specification of 30*10 - 16 (160/205); rotating warning lights, semi - enclosed cab (without heater/air conditioner, door or window components).
A variety of auxiliary tools are available for selection, including construction buckets, enclosed sweepers, four - in - one buckets, four - point lifting lugs for snowplows, grab buckets, ditchers, manure scrapers, tree transplanters, rotators, milling machines, breaker hammers, forklift forks, etc.
| Max.Operation height | 4058mm |
| Height of the bucket hinge pin | 3077mm |
| Height to Cabin top | 2007mm |
| Max.horizontal height of the bucket bottom | 2908mm |
| Length without bucket | 2700mm |
| Length with bucket | 3413mm |
| Max. unloading height | 2303mm |
| Unloading distance | 675mm |
| Wheelbase | 999mm |
| Departure angle | 23° |
| Ground clearance | 185mm |
| Rear turning radius | 1627mm |
| Machine width | 1469mm |
| Width of the tire edge | 1740mm |
| Width of the bucket edge | 1780mm |
| Bucket capacity | 0.35m³ |
| Diesel fuel tank capacity | 88L |
| Hydraulic fuel tank capacity | 70L |
| Rated working capacity | 750kg |
| Overturning working capacity | 1500kg |
| Operation weight | 3003kg |
| Max. working speed | 12km/h |
| Standard Engine | Xinchai490 |
| Power | 36.8KW/2500rpm |
| Operation Method | Mechanical/Hydraulic control |
