| Place of Origin | China |
| Brand Name | HIGHTOP |
| Certification | CE，EPA，ISO，TUV |
| Model Number | HT60 |
The HT60 6-ton wheel excavator is engineered for diverse construction applications, delivering powerful performance with exceptional fuel efficiency. Equipped with a high-performance Yanmar 4TNV94L engine producing 36.2 kW of power, this machine handles demanding excavation tasks while minimizing operating costs.
Key features include:
Ideal for construction, municipal projects, and agricultural applications, the HT60 excels in versatility and productivity.
| ENGINE | |
|---|---|
| Emission Standard | China Stage III or Euro5/EPA4 |
| Make /Model | KUBOTA/V2607 |
| Power /Rotation speed | 36.2kw(50HP)@2000rpm |
| Number of cylinder | 4 |
| TRACK SYSTEM | |
| Maximum Travel speed | 2.4/4.3 km/h |
| Width of track shoe | 400mm |
| Number of track shoe per side | 40pcs |
| Number of upper roller per side | 1 |
| Number of bottom roller per side | 5 |
| PERFORMANCE PARAMETER | |
| Standard Bucket capacity | 0.21m³ |
| Swing speed | 11rpm |
| Maximum Grade ability | 35° |
| Maximum Bucket digging force | 48KN |
| Maximum Arm digging force | 35KN |
| Hydraulic system pressure | 28Mpa |
| Machine weight | 6100kg |
| Fuel tank | 87L |
| Hydraulic oil tank | 100L |
| MACHINE SIZE | |
| Overall dimension (L*W*H) | 5940mm*1880mm*2570mm |
| Height of cabin | 2600mm |
| Track length on ground(Axle base) | 1990mm |
| Track gauge | 1480mm |
| Minimum Ground clearance | 353mm |
| Swing radius at tail | 1689mm |
| WORKING RANGE | |
| Maximum Digging height | 5499mm |
| Maximum Dumping height | 3845mm |
| Maximum Digging depth | 3808mm |
| Maximum Vertical digging depth | 2983mm |
| Maximum Digging radius | 6128mm |
| Minimum swing radius | 2607mm |
| Maximum Lifting height of blade | 376mm |
| Maximum Cutting depth of blade | 474mm |
